Industrial Pump Troubleshooting Guide for Wastewater, Sewage and Dewatering Duties

Step 1: identify the exact symptom

Troubleshooting becomes faster when the site defines the symptom clearly.

Common symptoms include:

• Pump does not start.
• Pump starts but no discharge.
• Low flow.
• Repeated tripping.
• High current.
• Abnormal noise.
• Vibration.
• Frequent clogging.
• Overheating.
• Rapid wear.
• Poor performance after installation.

Do not replace parts before identifying the pattern. The same symptom can have multiple causes.

Problem 1: pump does not start

If the pump does not start, check electrical and control items first.

Review:

• Power supply availability.
• Phase condition.
• Fuse, breaker or overload trip.
• Control-panel status.
• Float or level-switch condition.
• Manual/auto selector.
• Cable damage.
• Motor protection relay.
• Loose terminals.
• Water ingress in junction or panel areas.

Electrical troubleshooting should follow site safety procedures. Do not energize damaged cables or flooded panels.

Problem 2: pump runs but no water is discharged

A pump may run without discharge if flow path, suction or head condition is wrong.

Check:

• Discharge valve position.
• Non-return valve blockage.
• Pipe blockage.
• Air lock.
• Pump rotation direction where applicable.
• Liquid level and submergence.
• Clogged suction or strainer.
• Impeller damage.
• Total dynamic head higher than expected.

For submersible sewage or dewatering pumps, also inspect the sump for settled solids, debris or low water level.

Problem 3: low flow

Low flow is one of the most common complaints. It can be caused by the pump, piping or system design.

Review:

• Actual head versus design head.
• Pipe diameter.
• Long discharge line.
• Excessive bends.
• Partially closed valve.
• Worn impeller.
• Clogged suction area.
• Wrong pump selection.
• Low voltage.
• Solids buildup in the line.

If low flow appears from the first day, review selection and installation. If it appears after months of operation, review wear, blockage and maintenance history.

Problem 4: repeated tripping

Repeated tripping should not be ignored. It may indicate motor overload or electrical protection issues.

Check:

• Current reading.
• Voltage balance.
• Overload setting.
• Phase loss.
• Cable condition.
• Impeller jam.
• High head or blocked discharge.
• Thick sludge or solids overload.
• Excessive start/stop frequency.
• Motor cooling/submergence condition.

If the pump trips under sludge or sewage load, review whether the actual liquid is heavier or more solid-laden than the original selection data.

Problem 5: frequent clogging

Frequent clogging is common in sewage, sludge and wastewater duties. It may be a pump-type issue or a system issue.

Review:

• Rags, wipes, plastics or fibrous solids.
• Screening quality.
• Pump free-passage suitability.
• Need for cutter pump.
• Wet-well solids buildup.
• Pipe velocity.
• Sump cleaning schedule.
• Pump placement.

If fibrous solids are the main issue, the submersible cutter pump route may be more suitable than a standard sewage pump.

Problem 6: vibration or abnormal noise

Vibration and noise can indicate hydraulic, mechanical or installation problems.

Check:

• Pump mounting or placement.
• Pipe support.
• Cavitation or air entry.
• Low liquid level.
• Impeller damage.
• Bearing or mechanical wear.
• Debris inside pump.
• Operation away from recommended duty point.
• Discharge pipe stress.

Do not continue operation if vibration increases quickly. Stop and inspect before major damage occurs.

Problem 7: overheating

Overheating can result from electrical, hydraulic or operating conditions.

Review:

• Current draw.
• Supply voltage.
• Frequency of starts.
• Motor protection.
• Cooling/submergence condition.
• Dry-run risk.
• Blocked discharge.
• Heavy sludge load.
• Pump operating point.

Submersible pumps must operate within suitable liquid and duty conditions. Low liquid level or dry-running can create serious damage.

Problem 8: rapid wear or corrosion

Wear and corrosion often indicate a mismatch between pump material and liquid conditions.

Check:

• Grit or abrasive solids.
• Sand or slurry content.
• pH range.
• Chemical exposure.
• Temperature.
• Coating condition.
• Seal condition.
• Operating hours.

For industrial wastewater, do not assume material compatibility. Actual wastewater data should be reviewed before selecting or replacing the pump.

Problem 9: repeated failure after replacement

If a new pump fails in the same way as the old pump, the root cause is often outside the pump.

Review:

• Wrong pump type.
• Wrong duty point.
• Poor installation.
• Pipe or valve issue.
• Electrical issue.
• Solids or chemical mismatch.
• Wet-well design problem.
• Missing maintenance routine.

Repeated failure is a signal to review the full system, not only the pump.

Troubleshooting checklist before calling a supplier

Prepare this information before asking for support:

• Pump application.
• Pump type and duty.
• Flow and head requirement.
• Actual symptom.
• When the symptom started.
• Current and voltage readings.
• Liquid type and solids profile.
• Recent maintenance history.
• Photos of sump, pump, pipe and panel.
• Alarm/trip history.
• Installation layout.
• Pipe length and discharge point.

For Flow Chem review, send these details through the Flow Chem contact page.

When troubleshooting points to wrong pump selection

A pump may need re-selection if:

• It cannot meet flow at actual head.
• It clogs repeatedly despite cleaning.
• It trips under normal process load.
• It wears too quickly due to abrasive solids.
• It corrodes in the application.
• It needs cutter action but does not have it.
• It is used for sludge/slurry when selected for cleaner water.

In these cases, review the product route and duty data before buying another similar pump.

Common troubleshooting mistakes to avoid

Avoid these mistakes:

• Replacing the pump without checking valves and piping.
• Ignoring actual head.
• Ignoring current readings.
• Ignoring solids and clogging pattern.
• Treating every failure as a motor defect.
• Not checking the sump or wet well.
• Not testing the standby pump.
• Running the pump despite severe vibration.
• Ignoring wastewater chemistry.
• Not documenting failures.

Good troubleshooting separates pump failure from system failure.
